Ford 5.0L / 5.8L HO V8 Firing Order Diagram 1-3-7-2-6-5-4-8 & Plug Wire Routing

5.0L/5.8L HO firing order diagram showing spark plug wire routing, distributor, and timing scale
5.0L/5.8L HO firing order diagram showing spark plug wire routing, distributor, and timing scaleOriginal file
5.0L/5.8L HO firing order diagram showing spark plug wire routing, distributor, and timing scale

Reference · 1987-1991 BroncoAll 111 schematics

Ford EEC-IV TPS Pinpoint Test DH Schematic - TP Sensor Connector Pinout Bolt Thread Pitch & Diameter Diagram - 1/2 Inch, 20 Threads Per Inch (SAE) Lug Nut Seat Types Diagram - Acorn/Tapered 60°, Mag Seat w/Washer & Ball Seat Ford 5.0L / 5.8L HO V8 Firing Order Diagram 1-3-7-2-6-5-4-8 & Plug Wire Routing 1990 Ford Bronco Component Location View 151-12-165 Amp Alternator Layout 1990 Ford Bronco Frame Rail Component Location View 151-11 - Connectors & Sensors 1990 Ford F-Series/Bronco Component Location View 151-10 - Full Body Connectors 1990 Ford Bronco Component Location View 151-9 - Full Body Wiring Diagram Ford 5.0 Fox Mustang Short Belt Routing Diagram - 84.5" & 70.5" vs Stock Integral Gear Power Steering Fluid Flow Diagram - Ford Bronco Gear Box Schematic 111schematics1987-1991 Ford Bronco More reference 1973-1974 Ford Point-Type Ignition System Circuit Diagram - Coil & DistributorWiring diagram Ford Canister Purge Regulator Valve (CANP 9C915) Test Procedure - Figure 11Service procedure Ford 5.8L important engine information decal with 10° BTDC timing check and ASF-32C plugSpec plate Ford 5.0L V8 PCV Valve & Hose Routing Diagram - 9A474, 6B890, 6A664Exploded parts Ford 5.0L/5.8L Air Throttle Body Assembly Diagram - Canister Purge Ports & TPSManual page 1990 Bronco Major Standard Equipment sheet with interior features and functional specs by trimBrochure Borgeson Steering Intermediate Shaft Measurement Diagram - U-Joint Length B & CBlueprint Ford Thermactor Combination Valve Diagram - Air Bypass/Control Ports LabeledVacuum routing 1990 Ford Bronco Fuse Panel Diagram: Fuse Positions, Amps & Circuits (11-2)Fuse chart Ford V8 Intake Manifold Bolt Tightening Sequence Diagram - Stud LocationsTorque spec

5.0L/5.8L HO firing order diagram (1-3-7-2-6-5-4-8) with anti-crossfire spark plug wire routing and 10-degree base timing.

Part of 1987-1991 Ford Bronco Schematics

AI caption · Photo 665 of 1787

This schematic shows the firing order and spark plug wire routing for the Ford 5.0L and 5.8L HO (High Output) V8 engines. The diagram depicts a top view of the engine with both cylinder banks: cylinders 1 through 4 on one bank and cylinders 5 through 8 on the other. Numbered callouts identify each cylinder position, and the illustration shows how the spark plug wires should be routed from the distributor to each cylinder. A prominent attention note warns that spark plug wires for cylinders 1, 3, 5, and 6 must be routed exactly as shown to prevent crossfire (induction firing between adjacent wires). The document states the firing order as 1-3-7-2-6-5-4-8 and notes that base ignition timing is 10 degrees. A timing scale graphic marked TC (top center), 10, 20, and 30 with an arrow at the 10-degree mark reinforces the base timing specification. A reader can use this document to correctly connect spark plug wires after distributor or wire replacement, verify cylinder numbering, and set base ignition timing on these HO engines.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What is the firing order for the Ford 5.0L / 5.8L HO engine?
The firing order is 1-3-7-2-6-5-4-8, as stated on the diagram.
What is the base ignition timing for the 5.0L/5.8L HO?
The document states base timing is 10°, shown on the timing scale with an arrow at the 10 mark.
Why do spark plug wires 1, 3, 5 and 6 need special routing?
The attention note says these wires must be routed as shown in the diagram to prevent crossfire.
How are the cylinders numbered on this engine?
Per the diagram, one bank has cylinders 1, 2, 3, 4 (front to rear) and the other bank has cylinders 5, 6, 7, 8 (front to rear).
