Ford Bronco 16-Pin Connector Pinout Diagram - Wire Color Codes (E4OD-related)

This document is a hand-drawn/computer-drawn pinout diagram for a 16-pin electrical connector, viewed with 'Front' and 'Top' orientation marked at the top of the connector body. The connector face shows 16 round pin cavities arranged in four rows of four, numbered 1 through 16 from right to left in each row (row 1: pins 1-4, row 2: pins 5-8, row 3: pins 9-12, row 4: pins 13-16). Below the diagram, a legend lists the wire color assigned to each pin: 1 Red/Blue, 2 Red Blue, 3 Black/Purple, 4 Purple/Orange, 5 Orange/Black, 6 Red/Yellow, 7 Grey/Red, 8 Light blue/Yellow, 9 Orange, 10 Grey/Blue, 11 Purple/Orange, 12 Purple/Yellow, 13 Blue/Black, 14 Blue, 15 Brown/orange, and 16 Black. The document does not name the vehicle, year, or the specific harness/component the connector serves, but it was uploaded to a 1992 Ford Bronco gallery alongside E4OD transmission and MLPS connector diagrams, suggesting it relates to the transmission wiring. A reader can use this diagram to identify pin positions and match wire colors when testing or repairing this 16-pin connector.
