Suzuki Samurai 8v EFI Diagnostic Connector Pinout - A/F Duty & Test Terminals

Diagnostic connector terminal identification diagram with A-D terminal legend
Diagnostic connector terminal identification diagram with A-D terminal legendOriginal file
Diagnostic connector terminal identification diagram with A-D terminal legend

Reference · 1986-1995 SamuraiAll 73 wiring diagrams

Connector A1: C204 pinout with wire color, circuit and swap notes for pins 1-18 Suzuki Samurai 8v EFI Swap ECM Connector C2 Pinout - Wire Colors & Circuits Suzuki Sidekick/Geo Tracker 8v EFI Swap into Samurai - ECM C1 Pinout & Wiring Engine control module wiring diagram with main relay, fuel pump relay, heated oxygen sensor and IAC valve Engine control module wiring diagram with pin numbers, control relay, distributor, fuel injector and sensors Suzuki Samurai 8v EFI Diagnostic Connector Pinout - A/F Duty & Test Terminals Suzuki Samurai Wiper & Washer Motor Wiring Diagram - Intermittent Relay Circuit Suzuki Power Window Wiring Diagram - Console Switch, Sub Switches & Motors Suzuki Samurai Power Window Wiring Diagram - Main Switch & Motor Circuit Suzuki Brake Warning Lamp Wiring Diagram - Fluid Level, Parking Brake, RWAL Suzuki Warning Lamp Wiring Diagram - Charge, Oil, Check Engine Lamps Suzuki Samurai Warning Controller Wiring Diagram - Seat Belt & Door Switches 73wiring diagrams1986-1995 Suzuki Samurai More reference Suzuki Samurai Spring-Over Leaf Spring Diagram - Features & Design CalloutsBrochure Suzuki Samurai 8v EFI Swap Wiring - Pin Colors & 8A-20 Diagram Index (Pg 4)Manual page Weathered embossed option code plate with three-letter codes and partial serial numbersSpec plate EGR and canister purge vacuum routing diagram with 13-item numbered component legendVacuum routing Photo of Purple Compact Car Front Wheel & Fender (Misfiled Samurai Doc Scan)Exploded parts Receiver-Mount Winch Drop-In Bumper Mounting Idea Diagram - 2 Inch Hitch TubeSchematic 1986 Suzuki Samurai Fuse Box Diagram - Main Fuse Block & Fuse Panel LayoutFuse chart 1987 Suzuki Samurai Fabrication Template - Hand-Drawn Full-Size Layout w/ DimsBlueprint Trail Tough Samurai Twisted T/T shift shaft installation instructions beside bagged shift shafts and gasketService procedure

Connector terminal identification diagram for a diagnostic connector showing A/F duty check, diagnosis, ground and test switch terminals.

Part of 1986-1995 Suzuki Samurai Wiring Diagrams

AI caption · Photo 357 of 366

This document is an annotated pinout diagram of a vehicle diagnostic connector, uploaded to a 1987 Suzuki Samurai gallery as part of an 8v EFI swap information set. The illustration shows the face of the diagnostic connector (labeled '1') with four terminals identified as A, B, C, and D. Red annotations mark the 'Index latch' at the top of the connector and identify the 'Freeze' terminals (C and D). A legend below the drawing defines each terminal: A is the A/F (air/fuel) duty check terminal, B is the diagnosis switch terminal, C is ground, and D is the test switch terminal (noted as 'Ign freeze'). Item 1 identifies the whole part as the diagnostic connector. A reader can learn which pins to use for pulling diagnostic codes or checking air/fuel duty cycle on the EFI system: grounding or jumpering the appropriate terminals (diagnosis switch, test switch, ground) as indicated. The document contains no year, model, part numbers, wire colors, or fuse information, only the connector terminal identification. It appears to accompany other 8-valve EFI swap reference pages in the same album.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What are the terminals on this diagnostic connector?
A = A/F duty check terminal, B = diagnosis switch terminal, C = ground, D = test switch terminal (Ign freeze). Item 1 is the diagnostic connector itself.
Which terminal is ground on the diagnostic connector?
Terminal C is ground.
Which terminals are used for the 'freeze' function?
The red 'Freeze' annotation points to terminals C (ground) and D (test switch terminal, noted 'Ign freeze').
How do I orient the connector correctly?
The diagram labels an 'Index latch' at the top of the connector, which can be used to orient the terminal positions (A and B on top, C and D below).
