What fuse powers the driver side power seat?

Fuse 112, a 30A fuse in the Central Junction Box (CJB), which is hot at all times.

What wire colors run to the seat motors?

RED/WHT and YEL/WHT for the forward/rearward motor, YEL/LT BLU and RED/LT BLU for the front up/down motor, and YEL/LT GRN and RED/LT GRN for the rear up/down motor.

What motors are in the left power seat motor assembly?

Three motors: forward/rearward, front up/down, and rear up/down.

Do Super Cab models use different switch pins?

Yes. The diagram shows separate pin numbers for Super Cab (marked 2) and except Super Cab (marked 1), e.g., power in at pin 4 except Super Cab vs. pin 7 on Super Cab.

Home/ Registry/ Ford/ Bronco/ 1992-1996/ “Eddie Bauer”/ Photo supermotors.net/registry/media/1007163

Ford Super Duty / Excursion Power Seat Wiring Diagram - Driver Seat Motor & Switch

Driver power seat adjust switch wiring diagram with color-coded circuits

‹ ›

Wiring diagram of the driver front seat adjust switch and power seat motor assembly with color-coded circuits.

AI caption January 2014 · Photo 1477 of 3001

This document is a wiring diagram for the driver-side (left) power seat circuit on a Ford truck (references to PICKUP, EXCURSION, and SUPER CAB variants indicate a Super Duty/Excursion application). Power originates from the Central Junction Box (CJB), Fuse 112 (30A), which is hot at all times, feeding a dark green (DK GRN) wire through connector C270I pin 5 to the driver side front seat adjust switch (pin 4 except Super Cab, pin 7 on Super Cab). The switch controls three seat motors in the left power seat motor assembly: forward/rearward, front up/down, and rear up/down. Wire colors from the switch to the motors are RED/WHT and YEL/WHT (forward/rearward), YEL/LT BLU and RED/LT BLU (front up/down), and YEL/LT GRN and RED/LT GRN (rear up/down), with pin numbers differing between Super Cab and non-Super Cab configurations. The ground circuit uses a black (BLK) wire through splice S301 (without heated seats) or S332 (with heated seats) to ground G900 on pickups or G301 on the Excursion. Switch functions shown include ST DN/ST UP, FWD/RWD, and two DN/UP positions. The diagram is stamped with reference number 185476.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What fuse powers the driver side power seat?: Fuse 112, a 30A fuse in the Central Junction Box (CJB), which is hot at all times.
What wire colors run to the seat motors?: RED/WHT and YEL/WHT for the forward/rearward motor, YEL/LT BLU and RED/LT BLU for the front up/down motor, and YEL/LT GRN and RED/LT GRN for the rear up/down motor.
Where does the power seat circuit ground?: Through a BLK wire via splice S301 (without heated seats) or S332 (with heated seats) to ground G900 on the Pickup or G301 on the Excursion.
What motors are in the left power seat motor assembly?: Three motors: forward/rearward, front up/down, and rear up/down.
Do Super Cab models use different switch pins?: Yes. The diagram shows separate pin numbers for Super Cab (marked 2) and except Super Cab (marked 1), e.g., power in at pin 4 except Super Cab vs. pin 7 on Super Cab.
