What are the overall dimensions shown on this tank sketch?

The FRONT view shows a 48-inch overall length (with a 30-inch stepped section) and the SIDE view shows 38 inches overall, with heights/spans of 6", 6", 16", 18, 14", and 4" defining the tapered profile.

What views does the drawing include?

It includes an isometric 3-D sketch with an arrow labeled FRONT, a TOP view with dashed hidden lines, and dimensioned FRONT and SIDE views.

Does the drawing specify the vehicle or tank material?

No. The only text besides dimensions and view labels is the name "MARK RICHARDS." No vehicle, material, capacity, or part numbers are given.

What shape is the tank in this blueprint?

It is a rectangular tank with an angled/notched section on one side, shown by the 16" sloped dimension and the 4" small end dimension in the SIDE view.

Home/ Registry/ Ford/ Bronco/ 1992-1996/ “molasses”/ Photo supermotors.net/registry/media/1130299

Custom Tank Blueprint Sketch - Hand-Drawn Dimensions (48" x 38") Ford Bronco

Hand-drawn dimensioned sketch of a box-shaped enclosure showing top, front and side views with measurements

‹ ›

Hand-drawn dimensioned sketch labeled Mark Richards showing top, front and side views of a box enclosure with inch measurements.

AI caption March 2018 · Photo 541 of 1477

This document is a hand-drawn dimensional sketch on graph paper, uploaded as "tank.jpeg" to a 1992 Ford Bronco gallery and signed/labeled "MARK RICHARDS." It appears to be a homemade blueprint for a custom tank (likely a fuel or water tank), drawn in three views: an isometric (3-D) perspective view with an arrow indicating the FRONT face, a TOP plan view with dashed hidden lines, and dimensioned FRONT and SIDE elevation views. The FRONT view shows an overall length of 48 inches with a 30-inch dimension on a stepped lower section. The SIDE view shows a 38-inch overall dimension, two 6-inch height dimensions, a 16-inch dimension along an angled top face, an 18-inch span, a 14-inch span, and a 4-inch dimension at one end, describing a tank with a tapered or notched profile. No part numbers, materials, capacities, vehicle year, make, or model are stated anywhere on the drawing. A reader can learn the general shape and outside dimensions needed to fabricate or order this custom tank, but nothing about fittings, wall thickness, baffles, or mounting.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What are the overall dimensions shown on this tank sketch?: The FRONT view shows a 48-inch overall length (with a 30-inch stepped section) and the SIDE view shows 38 inches overall, with heights/spans of 6", 6", 16", 18, 14", and 4" defining the tapered profile.
What views does the drawing include?: It includes an isometric 3-D sketch with an arrow labeled FRONT, a TOP view with dashed hidden lines, and dimensioned FRONT and SIDE views.
Does the drawing specify the vehicle or tank material?: No. The only text besides dimensions and view labels is the name "MARK RICHARDS." No vehicle, material, capacity, or part numbers are given.
What shape is the tank in this blueprint?: It is a rectangular tank with an angled/notched section on one side, shown by the 16" sloped dimension and the 4" small end dimension in the SIDE view.
