Ford Bronco Timing Chain & Sprocket Diagram - Cam/Crank Gear Schematic

This document is an untitled, unlabeled line-art schematic depicting an automotive timing chain assembly. It shows a large upper camshaft sprocket with cutout openings in its face and a smaller lower crankshaft sprocket, both wrapped by a double-row style timing chain drawn with visible link pins. Dash-dot centerlines pass vertically and horizontally through both sprockets, indicating shaft centers and alignment. The scan was uploaded to a 1995 Ford Bronco gallery (filename "timing.gif") alongside related engine reference images such as a 5.8L firing order diagram, engine views, oil pan diagrams, and transmission schematics, suggesting it is intended as a visual reference for timing chain/sprocket arrangement during engine service. However, the drawing itself contains no text: no year, make, model, engine designation, part numbers, torque specifications, or timing-mark instructions are shown. A reader can learn only the general physical arrangement of the timing set — how the chain wraps the two sprockets and their relative sizes and centerline alignment. Anyone needing specific timing alignment marks, installation procedures, or fastener specifications would need additional documentation, since none appear on this schematic.
