What fuse powers the power windows and what is its rating?

The circuit is fed from I/P fuse panel position 14 through a 20A circuit breaker (c.b.), on a circuit that is hot in ACC or RUN.

What wire colors go to the left window motor?

Circuit 227 Yellow and circuit 226 White/Black run from the left window switch to the left window motor.

What wire colors feed the right window motor?

The right window control switch outputs circuit 333 Yellow/Red (pin 9) and circuit 334 Red/Yellow (pin 10) to the right window motor.

What circuit supplies power to both window switches?

Circuit 400, a Light Blue/Black wire, feeds power from fuse 14 to both the left and right window switches.

How are the window switches grounded?

Both window switches are grounded through circuit 57, a Black wire.

Home/ Registry/ Ford/ Bronco/ 1992-1996/ “pukin' dogII”/ Photo supermotors.net/registry/media/877818

1996 Ford Bronco Power Window Wiring Diagram - Switches, Motors & Wire Colors

Wiring diagram of power window circuit with left and right window switches, control switch and motors

‹ ›

Power window wiring diagram showing left and right window switches, master control switch and window motors with color-coded wires.

AI caption July 2011 · Photo 108 of 224

This document is a power window wiring diagram, uploaded for a 1996 Ford Bronco. It shows the complete electric window circuit: power originates at instrument panel fuse position 14, protected by a 20A circuit breaker (c.b.), on a circuit labeled 'HOT IN ACC OR RUN.' Circuit 400 (light blue/black wire) feeds both the left and right window switches. The left window switch controls the left window motor through circuits 227 (yellow) and 226 (white/black). The right window switch feeds circuits 313 (white/yellow) and 314 (tan/light blue) to a separate right window control switch (passenger door), which drives the right window motor through pins 9 and 10 via circuits 333 (yellow/red) and 334 (red/yellow). Both master switches are grounded through circuit 57 (black). Each switch has UP and DOWN positions that reverse motor polarity. A note refers readers to EVTM Cell 100 for more circuit details, indicating this is from a Ford Electrical & Vacuum Troubleshooting Manual style source. The diagram number N16296-B appears at bottom right. This diagram is useful for diagnosing inoperative power windows, tracing wire colors, and identifying the fuse/circuit breaker location.

Is this accurate? Sign in to help verify it.

Frequently asked questions

What fuse powers the power windows and what is its rating?: The circuit is fed from I/P fuse panel position 14 through a 20A circuit breaker (c.b.), on a circuit that is hot in ACC or RUN.
What wire colors go to the left window motor?: Circuit 227 Yellow and circuit 226 White/Black run from the left window switch to the left window motor.
What wire colors feed the right window motor?: The right window control switch outputs circuit 333 Yellow/Red (pin 9) and circuit 334 Red/Yellow (pin 10) to the right window motor.
What circuit supplies power to both window switches?: Circuit 400, a Light Blue/Black wire, feeds power from fuse 14 to both the left and right window switches.
How are the window switches grounded?: Both window switches are grounded through circuit 57, a Black wire.
