1986 Ford Bronco Long Travel Suspension CAD Schematic - Coil & Radius Arm Mockup

This document is a 3D CAD rendering (illustration only, no text) apparently depicting a long-travel suspension setup or fabrication mockup, uploaded to the gallery of a 1986 Ford Bronco under the filename 'LongTravel01.jpg'. The rendering shows a tall white bracket/tower structure mounted to a gray flat base plate representing a frame or floor section. Attached components include a coil spring with what appears to be a shock absorber or damper passing through it, an upper spring mount, a lower control/radius arm linkage with pivot brackets, and additional longitudinal arms or rails extending rearward along the base plate. Several bolts or cross-shafts protrude from the upper tower structure. Because the image contains no dimensions, part numbers, torque specifications, or textual annotations, a reader can only learn the general geometry and component arrangement of the proposed or modeled long-travel suspension design — such as the relative placement of the coil spring, shock, and radius arm mounts. No year, make, or model applicability is stated within the document itself; the 1986 Ford Bronco attribution comes solely from the uploader's gallery classification.
